DISC PLOUGH ADP
The disc harrow is a suspended soil cultivation machine primarily used for soil preparation in preparing the seedbed after harvest, attached to the tractor with a three-point linkage system.
Disc harrows operate with the discs rotating in the working position, so they do not get stuck on obstacles. In sandy and stony fields, disc wear is less than that of mouldboard ploughs. As they operate by rotating, they do not require excessive traction power from the tractor and do not strain it. It is a machine with simple settings and easy operation.
Advantages of using a disc plough:
*In moist soils worked with disc ploughs, the wavy structure of the furrow bottom prevents mud formation in the soil.
*The concave structure of the discs breaks up the soil more effectively, preventing clod formation.
*As the discs operate by rotating, they easily overcome obstacles such as stones and hard plant roots, preventing potential breakdowns and blockages.
*As the force distribution related to soil resistance is spread over a wide surface area on the discs, they are resistant to high forces in terms of strength and are not easily damaged.
*As the edges of the discs are sharpened from the outside, they rub against the sharp edge of the plough wall during operation and gradually sharpen themselves over time.
FOLDABLE V-TYPE OFFSET GOBLE DISCAROV LGD-KV
Hydraulic lift-equipped folding V-type offset disc harrows are trailed machines used to cut and shred crop residues (maize, sunflower, wheat, etc.) and weeds after harvest, and to break up the crust layer.
After harvesting, it prepares the field for direct sowing without the need for another agricultural machine by performing stubble-free soil cultivation during dry months when ploughs cannot be used. In addition to this feature, it can be used for cultivating soil with high moisture content.
The LGD - KV model offset disc harrows move with a hydraulic system and, due to their multi-directional movement capability, prevent wind and water erosion while breaking up stubble. The mechanism on the wheel ensures that the wheel runs at ground level, allowing the working depth to be effectively adjusted.
It has a greater working width than other soil cultivation machines. It is much more economical than other soil cultivation machines because it has a higher working speed and greater working width. Due to these features, fuel, time, labour, maintenance and spare part costs are lower. It reduces the share of soil cultivation in the total cost.
Hydraulic cylinders are used to enable the wings to open and close in working and road positions, allowing tools with a working width greater than three metres to be transported on roads. This enables easy transport in a folded position on roads and narrow transport routes.
LASER LEVELLING MACHINE
Zero, single or double-sloped laser selection option.
High-strength, heat-treated replaceable blades.
Blades designed with the optimal cutting angle for maximum efficiency,
resulting in low pulling force requirements.
All connection points are flanged and lubricated.
Our 3.5, 4, 4.5, 5, 5.5 and 6 metre laser levelling machines offer more balanced and stable operation during levelling thanks to the special side working wheels offered in the system, designed specifically for optional models.
The laser equipment is designed for all kinds of difficult and harsh working conditions
and has a waterproof feature that allows it to operate even under 3 metres of water
.
User manual and film.
All laser equipment is delivered in special cases made of lightweight material that is resistant to impacts and drops.
Easy and quick to set up, durable, laser transmitter stand.
MOUNTED ROLLER
Hanging and drawn rollers are used on small plots. Their primary function is to compact the soil. They are used to crush and break up clods that cannot be broken up by soil cultivation tools and to level the field surface. Rollers can be used on the field before and after sowing. When inserted before sowing, they crush the clods of the tilled field, compact the soil, and create a balance between air pockets, regulating the soil's water-air ratio and preparing a good seedbed.
After sowing, they help increase the contact between the seeds and the soil, bringing the water in the lower layers closer to the area where the seeds are located, thus aiding germination.
The materials used in rollers undergo all kinds of inspections and pass through a testing phase before reaching the manufacturing stage, and high-quality materials are used.
Thanks to its design, it is a machine with simple settings and extremely easy to use.
Optional 390 mm and 340 mm diameter flywheels can be fitted.
It can be used both suspended and towed thanks to a pin.
The profiles on the roller flywheels and gear create small depressions on the soil surface, increasing water retention and reducing surface runoff.
SPRING – LOADED LEG DISK HARROW SDH
The spring-loaded disc harrow, with its spring-loaded independent disc structure and machine construction, performs a more effective cutting and mixing process than conventional disc harrows, with each disc operating independently thanks to its separate bearing. The springs on each disc prevent breakages and damage to the frame by allowing the discs to move back and forth when encountering an obstacle. It is less affected by the unevenness of the terrain. It causes almost no damage to the levelling of the terrain. In addition, the roller attached to the chassis presses the soil lifted by the discs at the same time, minimising moisture loss after the process. The machine can operate comfortably in heavy clay soils.
THREE-HANGER DOUBLE BALANCED WHEEL VANVEY VNY
The Vanvey is a second-class soil cultivation machine. These are tools inserted into the field after ploughing, specifically to prepare a ploughed field for sowing. The process of breaking up the clods created by the plough to make the field surface more suitable for sowing is called double ploughing.
The three-point, dual-balance wheeled Vanvey is a suspended soil cultivation machine used for soil cultivation such as subsoiling and triple tillage in fields that have been left fallow for a year after being ploughed, as well as for breaking up weeds in vineyards, gardens and fields and aerating the soil.
The purpose of using a vanvey is to:
*Prepare the seedbed by breaking up the soil sufficiently.
*Kill weeds in fallow farming methods and preserve moisture accumulation in the soil by preventing evaporation from the soil.
*Break up plant debris on the soil surface and ensure that organic debris in the topsoil layer mixes with the soil.
*To break up the crust layer and sometimes partially compact the soil, thereby creating better soil conditions and accelerating germination.
